Caldera cleaver brooks de 200 Hp

Cleaver Brooks Steam Boiler, 6,900 Lbs/Hr, 8,869,000 Btu/Hr, Model Cb200-200, 200 Hp, Mawp 150 Psi, Fuel Natural Gas/Oil Fired,
Cleaver Brooks 200 Hp 150 Psi High Pressure Steam Boiler
Equipment Description
Manufacturer: Cleaver Brooks
Model: Cb200-200
Boiler Horsepower: 200 Hp
Boiler Type: Steam Boiler
Fuel Type: Natural Gas/Oil
Design Pressure Or Maximum Allowable Working Pressure: 150 Psi
Heating Capacity: 8,869,000 Btu/Hr
Steam Capacity: 6,900 Lbs/Hr.
Serial No: L-79384
Gph Oil: 60
Electrical Requirements
Main Power Supply
Voltage: 460V
Phase: 3 Ph
Hertz: 60Hz
Ampacity: 14 Amp
Minimum Circuit Ampacity: 18 Amp
Maximum Rating Of Circuit Protection: 56 Amp
Blower Motor
Horsepower: 10 Hp
Air Compressor Motor
Horsepower: N/A
Oil Heater: N/A
Control Circuit
Volts: 120V
Phase: 1 Ph
Hertz: 60 Hz
Ampacity: 7 Amp
Oil Pump Motor
Volts: 115V
Phase: 1 Ph
Hertz: 60Hz
Ampacity: 7 Amp
MODEL: CB200-200
